Industrial gas tank containers are usually made of high-strength steel to withstand gas pressure and various forces during transportation. Industrial gas tank containers usually have certain insulation properties to ensure a stable temperature of the gas during storage and transportation. Industrial gas tank containers will be marked with important information such as gas type and pressure to ensure correct handling and operation. The container itself needs to comply with ISO standards, such as ISO 9001 (Container Specification), etc., and also have certificates such as ASME-U2.
Product Overview:
The main features of CIMC ENRIC Industrial Gas Tank Containers are their design and structure. CIMC ENRIC Industrial Gas Tank Containers are designed to store and transport various types of industrial gases safely and efficiently. The high-strength structure, thermal insulation performance, safety valve leak detection system, standardized shape and size of CIMC ENRIC Industrial Gas Tank Containers ensure the safety, stability and operability of gas to meet the needs of different industries.
Product Features:
1.CIMC ENRIC Industrial Gas Tank Containers have a unique internal structural design, outstanding thermal insulation performance , long-distance loss-free transport;
2.CIMC ENRIC Industrial Gas Tank Containers have GB150, ASME, AS1210, EN13530 and other relevant domestic and foreign standards;a larger volume and a lower weight; safe and easy to operation;
3.CIMC ENRIC Industrial Gas Tank Containers comply with IMDG, ADR, RID and other international requirements on the transport of dangerous goods, suitable for global multimodal transportation;
4.The LR, BV, DNV, CCS or other relevant requirements for the inspection and certification of products.
Specifications
| 10ft OFFSHORE Cryogenic Tank Container | ||||||
| DAG.NO | Design Code | MAWP(MPa) | Capacity(m3) | Tare Weight(kg) | Load weight(kg) | Rated weight(kg) |
| CASIS-10-0.6 | ASME/GB | 6bar | 7.62 | 5300 | 5900 | 11200 |
| CASIS-10-2.2 | ASME | 22bar | 7.8 | 7800 | 8700 | 16500 |
| 20ft Cryogenic Tank Container (Side Opening door) | ||||||
| DAG.NO | Design Code | MAWP(MPa) | Capacity(m3) | Tare Weight(kg) | Load weight(kg) | Rated weight(kg) |
| CASIS-20-1.6-S | ASME | 1.6 | 21.1 | 7500 | 28500 | 36000 |
| CASIS-20-1.8-S | ASME | 1.8 | 21.1 | 7800 | 28200 | 36000 |
| CASIS-20-2.4-S | ASME | 2.4 | 21.1 | 8800 | 27200 | 36000 |
| CENIS-20-1.8-S | EN | 1.8 | 21.4 | 8600 | 27400 | 36000 |
| CENIS-20-2.4-S | EN | 2.4 | 21.1 | 10000 | 26000 | 36000 |
| 20ft Cryogenic Tank Container (Back Opening door) | ||||||
| DAG.NO | Design Code | MAWP(MPa) | Capacity(m3) | Tare Weight(kg) | Load weight(kg) | Rated weight(kg) |
| CASIS-20-1.6-B | ASME | 1.6 | 20.2 | 7200 | 28800 | 36000 |
| CASIS-20-1.8-B | ASME | 1.8 | 20.2 | 7550 | 28450 | 36000 |
| CASIS-20-2.4-B | ASME | 2.4 | 20.2 | 8400 | 27600 | 36000 |
| CASIS-20-3.5-B | ASME | 3.5 | 20.2 | 10250 | 25750 | 36000 |
